To browse Academia. Skip to main content. You're using an out-of-date version of Internet Explorer. Log In Sign Up. Bhor Akshay Ramhari1, Mr. Churi Vishal Madhukar2, Mr. Shinde Avinash Haribhau3, Mr. Chaudhari Bhushan Bhagwant4, Prof. However due to its cantilever type structure, the manipulator is inherently not very rigid and thus the link connecting the assembly to the bed is the most vulnerable to failure due to bending load.

It is poor in dynamic performance in high speed and heavy duty operations. Hence suitable for light duty and medium speed operations. The mechanical efficiency of pantograph mechanisms and conventional open-chain and closed-chain type manipulators are studied and evaluated using the concept of modified geometric work. The kinematics of 2-DOF pantograph type manipulators are studied and special: mechanisms which simplify the kinematics are introduced.

The kinematics of 6-DOF pantograph type manipulators are studied and special: mechanisms which simplify the kinematics are introduced. From that die getting only one shape which is shape of punch of die. To overcome this problem this we have been developing and fabricating pantograph sheet metal cutting machine for cutting of sheet metal up to of mm thickness of any complex shape. Hence this is very good tool to cut sheet of any complex shapes.

The advantage of this is that it has 3 DOF and each link having relative motion with respect to each other. So that stylus and tool can move in all direction for cutting of any complex shape. Initially the frame design is adopted from an already existing pantograph mechanism and minor changes are made to suite our purpose, the reducing and increasing of scale of an object.

The quarter hp motor is being to used on which reamer tool will be mounted for cutting operation. Adoption of frame design. Selection of link material. Selection of driving motor. Selection of tool for cutting operation. Selection of fixtures Figure 1 : Flow chart of methodology II.

LINKS A link is a resistant body that constituents the part of the machine connecting other parts which have motion relative to it. A slider crank mechanism of an IC engine consist of 4 links that is frame, crank, connecting rod and slider.

A binary link has two vertices, a ternary has three vertices, a quaternary link has four vertices and so on. Translational motions along any three mutually perpendicular axes x, y and z. Rotational motions about these axes. Degree of freedom of a pair is defined as the number of independent relative motions, both translation and rotational, a pair can have.

OQP is straight line. Point P describes a path similar to that described by Q. The pantograph is used as a copying mechanism. A1Q1 B1P1. The pantograph is used in geometrical instruments in the manufacture of irregular objects, to guide cutting tools and as indicator rig for cross-head. Link or Element:- Power Rating - 0. Cutting Tool:- Length - mm.

Type - Special Reamer 2. It is used to trace the drawings from paper to cut shape of that drawing on the sheet metal. If there is need of only few shapes it is not affordable to purchase die. To overcome this problem we have been developing and fabricating pantograph sheet metal cutting machine.
