Electronics Industry in Thailand. Original Equipment Manufacturing (OEM)

The diversity of processes and products within the microelectronics and semiconductor industry is immense. The focus of the occupational health and safety discussion in this chapter centres on semiconductor integrated circuit IC production both in silicon-based products and valence III-V compounds , printed wiring board PWB production, printed circuit board PCB assembly and computer assembly.

The industry is composed of numerous major segments. The Electronics Industry Association uses the following delineation in reporting data on pertinent trends, sales and employment within the industry:. Electronic components include electron tubes e. Consumer electronics include television sets and other home and portable audio and video products, as well as information equipment such as personal computers, facsimile transmission machines and telephone answering devices.

Electronic gaming hardware and software, home security systems, blank audio and video cassettes and floppy disks, electronic accessories and total primary batteries also fall under the consumer electronics heading.

While telecommunications, defence communications and industrial and medical electronics utilize some of the same technology these segments also involve specialized equipment. The pace of change within industrialized nations of the world has been greatly influenced by advances within this industry, specifically in the evolution of the integrated circuit. This pace of change is graphically represented in the timeline of the number of transistors per integrated circuit chip see figure The economic importance of worldwide semiconductor sales is significant.

Figure The semiconductor fabrication area has a high percentage of female operators that run the process equipment. The operator-related tasks typically do not require heavy lifting or excess physical strength.

Also, many of the job tasks involve fine motor skills and attention to detail. Male workers predominate in the maintenance-related tasks, engineering functions and management. This is especially true in the final assembly or back-end processes in the semiconductor industry. This processing involves the positioning and placement of the fabricated integrated circuit chip technically known as a die on a chip carrier and lead frame.

This processing requires precise positioning of the chip, typically through a microscope, and very fine motor skills. Again, female workers predominate this part of the process, with the majority of worldwide production being concentrated in the Pacific Rim, with high concentrations in Taiwan, Malaysia, Thailand, Indonesia and the Philippines, and growing numbers in China and Vietnam.

The semiconductor IC fabrication areas have various unusual properties and characteristics unique to this industry. Namely, the IC processing involves extremely tight particulate control regimens and requirements. A typical modern IC fabrication area may be rated as a Class 1 or less cleanroom.

As a method of comparison, an outdoor environment would be greater than Class ,; a typical room in a house approximately Class ,; and a semiconductor back-end assembly area approximately Class 10, To attain this level of particulate control involves actually putting the fabrication worker in totally enclosed bunny suits that have air supply and filtration systems to control the levels of particulates generated by the workers in the fabrication area.

The human occupants of the fabrication areas are considered very potent generators of fine particulates from their exhaled air, shedding of skin and hair, and from their clothing and shoes. See figure Also, in the photolithographic area, the processing involves exposing the wafer to a photoactive solution, and then patterning an image on the wafer surface using ultraviolet light. To alleviate unwanted ultraviolet UV light from this processing area, special yellow lights are used they lack the UV wavelength component normally found in indoor lighting.

These yellow lights help to make the workers feel they are in a different work environment and can possibly have a disorienting affect on some individuals. Asyst Technology, Inc. David G. Baldwin, James R. Rubin and Afsaneh Gerami. The description of silicon semiconductor device processing, either discrete devices a semiconductor containing only one active device, such as a transistor or ICs interconnected arrays of active and passive elements within a single semiconductor substrate capable of performing at least one electronic circuit function , involves numerous highly technical and specific operations.

The intent of this description is to provide a basic framework and explanation of the primary component steps utilized in fabricating a silicon semiconductor device and the associated environmental, health and safety EHS issues.

The fabrication of an IC involves a sequence of processes that may be repeated many times before a circuit is complete. The most popular ICs use 6 or more masks to complete patterning processes, with 10 to 24 masks being typical. The manufacture of a microcircuit begins with an ultra-high purity silicon wafer 4 to 12 inches in diameter. Perfectly pure silicon is almost an insulator, but certain impurities, called dopants, added in amounts of from 10 to parts per million, make silicon conduct electricity.

An integrated circuit can consist of millions of transistors also diodes, resistors and capacitors made of doped silicon, all connected by the appropriate pattern of conductors to create the computer logic, memory or other type of circuit. Hundreds of microcircuits can be made on one wafer. Six major fabrication processing steps are universal to all silicon semiconductor devices: oxidation, lithography, etching, doping, chemical vapour deposition and metallization.

These are followed by assembly, testing, marking, packing and shipping. Generally, the first step in semiconductor device processing involves the oxidation of the exterior surface of the wafer to grow a thin layer about one micron of silicon dioxide SiO 2. This primarily protects the surface from impurities and serves as a mask for the subsequent diffusion process. This ability to grow a chemically stable protective wafer of silicon dioxide on silicon makes silicon wafers the most widely used semiconductor substrate.

Oxidation, commonly called thermal oxidation, is a batch process which takes place in a high-temperature diffusion furnace. The protective silicon dioxide layer is grown in atmospheres containing either oxygen O 2 dry oxidation or oxygen combined with water vapour H 2 O wet oxidation.

Chlorine compounds in the form of hydrogen chloride HCl may also be added to help control unwanted impurities. The tendency in newer fabrication facilities is towards vertical oxidation furnaces. Vertical furnaces better address the need for greater contamination control, larger wafer size and more uniform processing. They allow a smaller equipment footprint that conserves precious cleanroom floor space. Silicon wafers to be oxidized are first cleaned, using a detergent and water solution, and solvent rinsed with xylene, isopropyl alcohol or other solvents.

The cleaned wafers are dried, loaded into a quartz wafer holder called a boat and loaded into the operator end load end of the quartz diffusion furnace tube or cell. The basic chemical reaction is:. The basic chemical reactions are:. Such systems are generally called burnt hydrogen or torch systems. Water vapour is produced when proper amounts of hydrogen and oxygen are introduced at the inlet end of the tube and allowed to react.

The mixture must be controlled precisely to guarantee proper combustion and prevent the accumulation of explosive hydrogen gas. High-pressure oxidation HiPox is technically called a water pyrosynthesis system and generates water vapour through the reaction of ultra-pure hydrogen and oxygen. The steam is then pumped into a high-pressure chamber and pressurized to 10 atmospheres, which accelerates the wet oxidation process.

De-ionized water may also be used as a steam source. Nitrogen or oxygen gas enters the inlet side of the bubbler, becomes saturated with water vapour as it rises through the water, and exits through the outlet into the diffusion furnace. Bubbler systems appear to be the most widely used method of oxidation.

In flash oxidation de-ionized water is dripped continuously into the heated bottom surface of a quartz container and the water evaporates rapidly once it hits the hot surface. Nitrogen or oxygen carrier gas flows over the evaporating water and carries the water vapour into the diffusion furnace. Lithography, also known as photolithography or simply masking, is a method of accurately forming patterns on the oxidized wafer. The microelectronic circuit is built up layer by layer, each layer receiving a pattern from a mask prescribed in circuit design.

These developments relate to the manufacture of printing plates, usually of metal, on which removal of material through chemical etching produces a surface relief pattern. This same basic technique is used in producing master masks used in the fabrication of each layer of processing of a device. Circuit designers digitize the basic circuitry of each layer. This computerized schematic allows quick generation of the mask circuitry and facilitates any changes that may be needed.

This technique is known as computer-aided design CAD. Utilizing powerful computer algorithms, these on-line design systems permit the designer to lay out and modify the circuitry directly on video display screens with interactive graphic capabilities. The final drawing, or mask, for each layer of circuitry is created by a computer-driven photoplotter, or pattern generator. These photoplotted drawings are then reduced to the actual size of the circuit, a master mask produced on glass with chrome relief, and reproduced on a work plate which serves for either contact or projection printing on the wafer.

These masks delineate the pattern of the conducting and insulating areas which are transferred to the wafer through photolithography. Most companies do not produce their own masks, but utilize those furnished by a mask producer. The need for a particulate- and contamination-free exterior wafer surface requires frequent cleaning. The major categories are:. Wafers are coated with a resist material of solvent-based polymer and rapidly rotated on a spinner, which spreads a thin uniform layer.

The solvents then evaporate, leaving a polymeric film. All resist materials depend on primarily ultraviolet radiation-induced changes in the solubility of a synthetic organic polymer in a selected developer rinse. Resist materials are classified as either negative or positive resists, depending on whether the solubility in the developer decreases negative or increases positive upon exposure to radiation.

Table Since most photoresists are ultraviolet UV light sensitive, the processing area is lit with special yellow lights lacking sensitive UV wavelengths see figure Negative and positive UV resists are primarily in use in the industry. E-beam and x-ray resists, however, are gaining in market share because of their higher resolutions.

Health concerns in lithography are primarily caused by potential reproductive hazards associated with selected positive resists e. Occasional odours from the negative resists e. Because of these concerns, a great deal of time is spent by semiconductor industry industrial hygienists sampling photoresist operations.

A 1 hour exposure to ethylene glycol monoethyl ether acetate of 6. This exposure was primarily caused by poor work practices during the maintenance operation Baldwin, Rubin and Horowitz After the resist has been applied, the wafers are moved on a track or manually moved from the spinner to a temperature-controlled oven with a nitrogen atmosphere.

To ensure adhesion of the resist layer to the wafer, a primer, hexamethyldisilizane HMDS , is applied to the wafer. The primer ties up molecular water on the surface of the wafer. HMDS is applied either directly in an immersion or spin-on process or through a vapour prime that offers process and cost advantages over the other methods. For the first mask, no alignment is necessary.

Oem Electronic Manufacturer In Malaysia

Sixteenth Census of the United States: : Manufactures: United States. Bureau of the Census. Personnel of manufacturing establishments and their salaries and wages by class of employment. Number of establishments number of wage earners average for year and value of products by type of operation and.

An Abrasive is a substance which grinds, cleans, scours, abrades or removes solid material by rubbing action or by impact. Abrasives are mineral like materials available in different shapes, sizes and types according to need.
